AMD EPYC “Venice” To Launch In 2026 As One Of The First 2nm Zen 6 CPUs Manufactured By TSMC

AMD has officially confirmed that its upcoming EPYC “Venice” processor line might be amongst the primary merchandise manufactured utilizing TSMC’s superior 2nm (N2) course of node. This announcement celebrates the long-standing partnership between AMD and TSMC and signifies a serious step ahead in high-performance computing (HPC) expertise. The Venice collection, based mostly on AMD’s future Zen 6 and Zen 6c architectures, is predicted to launch in 2026 and can mark a generational leap in CPU design and manufacturing.

In line with AMD, the EPYC Venice processors have reached the “tape-out” stage, which means their designs have been finalized and are actually prepared to start manufacturing. This milestone positions Venice because the trade’s first HPC-oriented chip to succeed in tape-out utilizing the N2 course of. The upcoming EPYC 9006 household will comply with the present EPYC 9005 “Turin” era and can possible debut within the latter half of 2026, following AMD’s typical launch cadence.

✅ Our next-gen EPYC processor, codenamed “Venice,” is the primary HPC product within the trade to be taped out and introduced up on the TSMC superior #2nm (N2) course of expertise.

— AMD (@AMD) April 14, 2025

Though AMD has not disclosed detailed specs of the Zen 6 structure, expectations are excessive for vital efficiency good points over Zen 5. Enhancements might embody elevated core counts and architectural refinements aimed toward additional optimizing effectivity and computational energy. These developments will cater to demanding HPC workloads resembling scientific analysis, simulations, and large-scale knowledge processing.

TSMC’s N2 course of introduces a number of key improvements, most notably the transition to GAAFET (Gate-All-Round Area-Impact Transistor) expertise. GAAFETs provide improved management over electrical present, resulting in higher energy effectivity and better transistor density. Moreover, the expertise permits chip designers to fine-tune transistor dimensions for efficiency, energy, or balanced optimization, providing enhanced flexibility in chip engineering.

Manufactured within the US

#TogetherWeAdvance: Our deep partnership with TSMC is bringing modern applied sciences to market that may energy essentially the most demanding knowledge heart purposes of the long run. https://t.co/vFLf3v7JuS pic.twitter.com/a1ilYdKf7S

— AMD (@AMD) April 14, 2025

In one other strategic transfer, AMD has confirmed that its present EPYC 9005 collection has been validated for manufacturing at TSMC’s Fab 21 facility in Arizona, USA. This manufacturing facility is TSMC’s first within the U.S. and a part of a broader initiative to diversify world semiconductor manufacturing. Fab 21 makes a speciality of 5nm and 4nm processes, and whereas no actual timeline was shared, manufacturing of the EPYC 9005 chips in Arizona is predicted to start later in 2025, with additional bulletins anticipated.
